Color management requires ICC-compliant profiles to render the Adobe Acrobat PDF document correctly on the output device. You can use and customize color profiles for monitors, input devices, output devices, and documents. An in-depth step by step Adobe Photoshop CS4 tutorial covering how to print using the correct color / ICC printer profiles. Using the correct printer profil.

Two of the most commonly used ICC profiles for RGB images are Adobe RGB (1998) and sRGB IEC61966-2.1. The Adobe RGB (1998) color space has a larger color gamut than the sRGB IEC61966-2.1 color space, but you may be surprised to see that they share many similarities.

In order to compare the two color spaces, I will use the CIE and ICC data that define the color spaces:

  1. Gamma value
  2. White point
  3. Red primary CIE chromaticity coordinates
  4. Green primary CIE chromaticity coordinates
  5. Blue primary CIE chromaticity coordinates

As you can see in the table, Adobe RGB (1998) and sRGB IEC61966-2.1 share the same values for four of the five attributes. The only difference is the set of CIE chromaticity coordinates for the green primary.

Now let me show you two versions of a sample image. For the first image, the sRGB IEC61966-2.1 ICC profile was assigned to the image in Adobe Photoshop. For the second image, the Adobe RGB (1998) ICC profile was assigned to the image in Adobe Photoshop. (Note: To make sure you see a difference between the two images, I converted the second image from Adobe RGB (1998) to sRGB IEC61966-2.1 so that both images are coded to the same color space. Yes, I could have coded both of them in the Adobe RGB (1998) color space to make sure no colors got clipped. Feel free to repeat this experiment in a color-managed display environment to see the color differences.)

sRGB IEC61966-2.1 ICC Profile

Adobe RGB (1998) ICC Profile

Adobe Icc Profiles

As you can see, the colors in the image with the sRGB IEC61966-2.1 ICC profile are significantly different from the colors in the image with the Adobe RGB (1998) ICC profile.

Based on the data comparison above, I would have expected the reds and blues to be similar in both images, and I would have expected the greens to be very different. However, the greens and blues have small shifts in color, and the reds and oranges have large shifts in color. Here is another set of images that demonstrates the color differences.

sRGB IEC61966-2.1 ICC Profile

Adobe RGB (1998) ICC Profile

Why do we see these large color differences in the reds and oranges when the only difference in the two color spaces is the set of CIE chromaticity coordinates for the green primary? The answer can be found in the CIE XYZ tristimulus values for the red, green, and blue primaries.

sRGB IEC61966-2.1 CIE XYZ Tristimulus Values

Adobe RGB (1998) CIE XYZ Tristimulus Values

The two color spaces share the same CIE chromaticity coordinates for the red and blue primaries, and share the same D65 white point and 2.2 gamma value, but the two sets of CIE XYZ tristimulus values are completely different.

To fully understand the differences when the images are viewed with proper color management, we have to look at the 3×3 matrix in the ICC profile. As I described in an earlier post, a chromatic adaptation transform must be applied to the CIE XYZ tristimulus values to force the 3×3 matrix to deliver the D50 white point that is required in the specification for ICC profiles. For the Adobe RGB (1998) and sRGB IEC61966-2.1 ICC profiles, the Bradford transform and proper von Kries scaling were used to move the white point from D65 to D50. The CIE XYZ tristimulus values in the 3×3 matrices are shown below.

sRGB IEC61966-2.1 ICC Profile 3×3 Matrix

Adobe RGB (1998) ICC Profile 3×3 Matrix

The CIE XYZ tristimulus values in these two 3×3 matrices help explain the color shifts seen in the two sets of example images. Further analysis can be done with these two matrices to compare the CIELAB values associated with a given set of RGB pixel values.

The point of this post is to alert people to be careful when comparing color spaces in color managed workflows. It is convenient to compare RGB color spaces based on the CIE chromaticity coordinates of the primaries, but it is difficult to predict the color differences in color-managed images from a comparison of CIE chromaticity coordinates of the primaries.

Post written by Parker Plaisted

Icc

References:
International Color Consortium, ICC Profile Format Specification, http://www.color.org

M. Fairchild, Color Appearance Models, Addison-Wesley, Reading, Massachusetts (1998).

Bruce Lindbloom Website, RGB Working Space Information page, http://www.brucelindbloom.com

On this page there is a set of ICC profiles, also knows as ICM profiles. These have been created from the data on Bruce Lindbloom's site, as well as information from Adobe, using the little cms toolkit.

Profiles tell you system how to display colors - they contain three key pieces of information:

  1. An exact definition of what the gamut of the color space is - in simple terms, what exact shade of red the R component is, the G component, etc
  2. A white point - these are often specified as a 'D number', one of the CIE standard illuminants e.g., D65 (6500K, overcast daylight) or D55(5500K, warm daylight)
  3. A Gamma curve - the way that we see light is non-linear, and many color systems mimic this

You can use these profiles in a number of ways:

  • If you have a raw developer program, such as Capture One, that directly supports ICC profiles, you can load and use these directly. So, for example, if under Capture One you wanted the screen readouts to be in WideGamut, you would just load WideGamut.icc as the output profile.
  • You can also convert color on the Mac by using the ColorSync utility's calculator; just select the appropriate profile in the calculator screen.

The profiles are in a single ZIP file, ICCProfiles.zip.

The root of the Zip file has the following profiles:

AppleRGB.icc

CIERGB.icc

MelissaRGB.icc

Adobe Icc Profiles

ProPhoto.icc

WideGamut.icc

Icc

The MelissaRGB profile deserves some explanation. Melissa RGB is not an 'official' color space, but is the combination of the ProPhoto color space, with an sRGB gamma curve. It's important because Melissa RGB is what Lightroom uses for its readouts. Specifically, the RGB values you get as Lightroom readouts are in this space. Note that the Melissa RGB profile I'm providing here has the real sRGB gamma curve. The sRGB gamma is close to a 2.2 gamma, but is linear at low values. So, if you take a readout of the darkest patch of the GretagMacBeth chart, there is is about a 1.5% difference between the reading using ProPhoto at a 2.2 gamma and a true Melissa RGB profile.

I also provide some alternate profiles in the 'Alternate' directory of the ZIP. This includes a 'ProPhoto gamma 2.2' file, for those that want to compare to the Melissa RGB version. These are all either at different to normal gammas, or different to normal white points:

MelissaRGBD65.icc

ProPhoto22.icc

ProPhoto22D65.icc

ProPhotoD65.icc

sRGB Gamma22.icc

WideGamutD65.icc

The file names should make the differences clear.

Adobe Icc Profiles Mac

In order to install these profiles, you need to do the following:

Adobe Icc Profiles For Windows

  1. On Windows systems, either just double click, or copy to the WINDOWSsystem32spooldriverscolor directory
  2. On Macs, copy to the /Users/Library/ColorSync/Profiles folder, or if you want them to have them available to all users and you are an administrator, to the /Library/ColorSync/Profiles folder
